Szczegóły Produktu:
Zapłata:
|
| Materiał ramy: | Metal | Rodzaj metalu: | Stal |
|---|---|---|---|
| Rodzaj drewna poddanego obróbce ciśnieniowej: | Obrobione cieplnie | Wykończenie ramy: | Malowane proszkowo |
| Funkcja: | Łatwy w montażu, zrównoważony, PRZYJAZNY EKOLOGICZNIE, FSC, poddany obróbce ciśnieniowej | Stosowanie: | Ogrodzenie ogrodowe, ogrodzenie autostradowe, ogrodzenie sportowe, ogrodzenie rolnicze, ogrodzenie w |
| Typ: | Ogrodzenia, kraty i bramy, ogrodzenie zabezpieczające, bramy podjazdowe, akcesoria do ogrodzeń | Praca: | Modelowanie 3D, przykładowe modele 3D, instrukcja, film z instalacji |
| Wysokość panelu: | 2,1 m, 2,4 m, 2,9 m | Szerokość panelu: | 2,5 m, 2,9 m |
| Średnica drutu: | 3,85/4mm | Otwór: | 76,2*12,7 mm |
| Obróbka powierzchniowa: | Powlekane PCV lub ocynkowane ogniowo | Kupujący komercyjny: | Domy towarowe |
| Zabarwienie: | Zielony RAL6005, czarny RAL9010, brązowy RAL i tak dalej | Styl projektowania: | przemysłowy, gospodarstwo rolne |
| E-mail: | devin@industrialmetalmesh.com | WhatsAPP: | +8615369013183 |
| Podkreślić: | 358 anti climb security fence,airport prison security fence,industrial boundary wire mesh fence |
||
As a trusted solution for engineering professionals and project developers, our 358 Anti-Climb Security Fencing combines superior anti-climb and anti-cut performance with long-term durability. Designed to lower total project costs and simplify installation, it is the preferred choice for prisons, airports, and other high-risk infrastructure projects.
Perimeter High Safety Galvanized Welded Wire Mesh Fencing Panel Metal Steel 358 Anti Climb Security Fence for Airport Prison Border Industrial Boundary
The panel mesh is welded with galvanized wire as per EN10244 and the post is shaped from galvanized coils as per EN10346.The bolts and nuts are stainless steel 304 .
Panel and post are powder coated with Akzo Nobel- Interpon 600 series powder and pass 500H-1000H salty spray followed by ISO9227.
Features:
Anti-Climb & Anti-Cut Structure: 76.2×12.7mm dense mesh eliminates hand and foot holds. High-tensile steel wire resists bolt cutters and hydraulic tools, effectively delaying intrusion.
Heavy-Duty Y-Type Post: Reinforced steel posts with prefabricated Y-arms for razor barbed tape installation, ensuring high impact resistance and long-term stability.
Dual Anti-Corrosion Treatment: Hot-dip galvanized + PVC/PE coating provides excellent weather resistance, ensuring 10+ years service life even in coastal or industrial environments.
Modular & Fast Installation: Standardized modules reduce on-site labor time and installation costs, accelerating project schedules.
Full Compliance & Certifications: ISO 9001, Complete test reports including tensile strength, salt spray, and impact resistance are available for project bidding and approval.
Custom Engineering Support: Custom heights, colors, mesh specifications, and structural design. CAD drawings and technical documents are provided to support your project submission.
|
Mesh
|
Wire Diameter
|
Panel Width
|
Panel Height
|
Post Type
|
|
|
76.2x12.7mm
75x12.5mm
75x25mm
75x50mm
|
Horizantal Wire: 3.2, 3.5, 4mm
Vertical Wire: 4mm
|
1m-3m
popular: 2.2m/2.5m/3m
|
1m-6m
popubr: 2.5m/3m
|
Square Post(SHS) 60x60x2/2.5/3mm 80x80x2/2.5/3mm
|
Roctangular Post(RHS) 40x60x2/2.5/3.0mm 40x80x2/2.5/3.0mm 60x80x2/2.5/3.0mm
|
|
Surface Treatment: hot dipped galvanized, galvanized + powder coated
|
|||||
|
V-top: including angle iron, barbed wire,razor barbed wire
|
|||||
|
Connecting Methods: iom bar, hexagonal clamp, screws
|
|||||
|
Color: RAL 6005 green, RAL 7016 gray, All RAL color can be customized
|
|||||
| Horizontal Wire and Vertical Wire With V Fold 358 Security Fence | ||||||
| Mesh Opening | Wire Thickness | Panel Width | Panel Height | Number of Folds | Post Type | |
|
76.2*12.7mm (3''*0.5'') |
3.0mm or |
2.0m or 2.50m |
1830mm | 3 | Square Post(SHS) 50X50x1.5/2.0mm 60x60x1.5/2.0mm 80x80x1.5/2.0mm |
Rectangular Post(RHS) 40x60x1.5/2.0mm 40x80x1.5/2.0mm 60x80x1.5/2.0mm 80x100x1.5/2.0mm |
| 1930mm | 3 | |||||
| 2030mm | 4 | |||||
| 2230mm | 4 | |||||
| 2430mm | 4 | |||||
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating | ||||||
| Color: RAL 6005 green, RAL 7016 gray, RAL 9005 black,All RAL color can be customized. | ||||||
| Note: The fence can be customized according to your required if above specification is not satisfied with you | ||||||
| Horizontal Wire and Vertical Wire 358 Security Fence | |||||
| Mesh Opening | Wire Diameter | Height of Fence | Width of Fence | Post Type | |
| 12.7x76.2mm (0.5'' x 3'') |
3/3.5/4mm | 1.2-2.5m | 2.0-3.1m | Square Post(SHS) 60x60x2.0/2.5/3.0mm 80x80x2.0/2.5/3.0mm |
40x60x2.0/2.5/3.0mm 40x80x2.0/2.5/3.0mm 60x80x2.0/2.5/3.0mm |
| Surface treatment:hot dipped galvanized, galvanized +powder coated, galvanized +PVC coating | |||||
| Color: RAL 6005 green, RAL 7016 gray, All RAL color can be customized. | |||||
| Note: The fence can be customized according to your required if above specification is not satisfied with you | |||||
