Szczegóły Produktu:
Zapłata:
|
| Kształt dziury: | Kwadrat, prostokąt, długa otwór | Wskaźnik drutu: | 0,5 mm-14 mm, 2,0-4,0 mm, BWG # 12 -- # 26,0,3-2,5 mm, 0,3 mm-8,0 mm |
|---|---|---|---|
| Aplikacja: | Siatka konstrukcyjna, siatka ogrodzeniowa, budynek, most, płot ogrodowy | Typ: | Spawana siatka, elektryczna siatka druciana, panel lub rolka |
| Otwór: | 1/2", 1/4"-6", 1" x 2" itp | Obróbka powierzchniowa: | Ocynkowane ogniowo, powlekane PCV, ocynkowane / powlekane PCV, malowane proszkowo |
| Szerokość: | 0,5-2m,0,5-1,8m,300mm-2500mm,0,5m do 2,2m,1,2m | Długość: | 30m, 50m, 10m, 5m, 25m |
| Stosowanie: | Ochrona, budynek, budowa | uszczelka: | Paleta, luzem |
| Nazwa produktu: | spawana siatka druciana, ocynkowana / powlekana PVC spawana siatka druciana | Kolor: | srebrny, zielony, szary itp |
| Nazwa: | spawana siatka druciana, Stone Cage Net, sprzedaż spawanej siatki drucianej z betonu zbrojonego PCV | rozmiar otworu: | 5/8 '' na życzenie klienta |
| Średnica drutu: | 1,0 mm ~ 4,50 mm | Rozmiar siatki: | 50x100mm |
| E-mail: | devin@industrialmetalmesh.com | WhatsApp: | +8615369013183 |
| Podkreślić: | 1/2 inch stainless steel welded wire mesh,1.4mm SUS304 welded mesh for cages,stainless steel wire mesh for poultry |
||
Welded wire mesh panels material: black iron wire, galvanized before welding, galvanized after welding, hot-dipped galvanized welding, PVC coated, PE Coated, Powder coating. Welded wire mesh panels made from galvanized wire or black iron steel wire can also be PVC-coated or powder-coated to shield them from corrosion and rust.
Welded wire mesh panels can be used for a wide range of applications, usage as below: security cages, security fencing, metal fencing, dog fencing, animal enclosures, aviaries, bird cages, pet hutches, cat fences, pond covers or protection, garden fencing, and construction materials.
Welded wire mesh is high-quality low low-carbon steel wire welded row, and then cold plating (electroplating), hot galvanized, PVC-coated surface passivation, and plastics processing. To achieve a smooth surface, uniform mesh, strong joints, local good mechanical properties, stability, corrosion corrosion resistance.
Material:Low carbon steel wire, Stainless steel 302, 304, 304L, 316, 316L, Special materials, specifications can be customized according to customer requirements
|
Specification
|
||
|
Opening
|
Wire Diameter
|
|
|
Inch
|
metric Unit(mm)
|
|
|
1"x1"
|
25mmx25mm
|
2.5mm,2.0mm,1.8mm,1.6mm
|
|
2"x2"
|
50mmx50mm
|
2.5mm,2.0mm,1.8mm,1.6mm
|
|
2"x3"
|
50mmx70mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm
|
|
2"x4"
|
50mmx100mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.0mm
|
|
2"x6"
|
50mmx150mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
2"x8"
|
50mmx200mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
3"x3"
|
75mmx75mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm,1.6mm
|
|
3"x4"
|
75mmx100mm
|
6.0mm,5.0mm,4.0mm,3.0mm,2.5mm,2.0mm,1.8mm
|
|
4"x4"
|
100mmx100mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
5"x5"
|
125mmx125mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
6"x6"
|
150mmx150mm
|
6.0mm,5.0mm,4.0mm,3.0mm
|
|
Technical Note:
|
||
|
1.Standard Panel Length:0.5m-5.8m;Width:0.5m-2.4m
2.Special size available at request |
||
|
Specification of Welded Wire Mesh
|
||||
|
Opening
|
|
0.4-2M Length 5-50m |
electric galvanized after welded, hot-dipped galvanized before welded, hot-dipped galvanized after welded, PVC coated, Stainless steel wire |
|
|
In inch
|
In metric unit
|
|||
|
1/4" x 1/4"
|
6.4 x 6.4mm
|
BWG24-22
|
||
|
3/8" x 3/8"
|
10.6x 10.6mm
|
BWG22-19
|
||
|
1/2" x 1/2"
|
12.7 x 12.7mm
|
BWG23-16
|
||
|
5/8" x 5/8"
|
16x 16mm
|
BWG21-18
|
||
|
3/4" x 3/4"
|
19.1 x 19.1mm
|
BWG21-16
|
||
|
1" x 1/2"
|
25.4x 12.7mm
|
BWG21-16
|
||
|
1-1/2" x 1-1/2"
|
38 x 38mm
|
BWG19-14
|
||
|
1" x 2"
|
25.4 x 50.8mm
|
BWG16-14
|
||
|
2" x 2"
|
50.8 x 50.8mm
|
BWG15-12
|
||
|
2" x 4"
|
50.8 x 101.6mm
|
BWG15-12
|
||
|
4" x 4"
|
101.6 x 101.6mm
|
BWG15-12
|
||
|
4" x 6"
|
101.6 x 152.4mm
|
BWG15-12
|
||
|
6" x 6"
|
152.4 x 152.4mm
|
BWG15-12
|
||
|
6" x 8"
|
152.4 x 203.2mm
|
BWG14-12
|
||
|
Note: Special specifications can be made according to customers requires.
|
||||
| Welded wire mesh | |
| Material | Galvanized wire |
| surface | Surface passivation of cold plating (electroplating), hot plating, PVC, etc |
| wire diameter | 0.5-14mm |
| Aperture | 6-50mm |
| width | 1-2 meters or customized |
| length | 5-50 meters or customized |
| application | Industry, agriculture, breeding, construction, transportation, mining, etc. |
| Wire Diameter(mm) | Aperture (mm) | Width(m) | Length | |
| Inch | MM | |||
| 2.0mm-3.2mm | 1" | 25.4 | 0.914m-1.83m | commonly under 6 m per piece if loaded in 20', commonly under 12 m per piece if loaded in 40', |
| 2.0mm-4.5mm | 2" | 50.8 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 3" | 70.2 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 4" | 101.6 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 5" | 127 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 6" | 152.4 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 7" | 177.8 | 0.914m-2.75m | |
| 2.0mm-6.0mm | 8" | 203.2 | 0.914m-2.75m | |
5. Welded wire mesh Packing:
>About welded wire mesh panel in wooden or steel pallet,50 to 500 piece per pallet.
>About welded wire mesh roll in water-proof paper.
(customer's packing is available on request.
